The four-cylinder alternative in BMW's retractable hardtop roadster. The N20-powered sDrive28i replaced the naturally aspirated inline-six in the E89 lineup from September 2011, delivering 245 PS through a single twin-scroll turbo. Available from launch with a 6-speed manual or an optional 8-speed automatic, it combines respectable straight-line performance with lower fuel consumption than the six-cylinder variants. The retractable hardtop offers coupe-like weather protection but adds mechanical complexity that demands attention.· more· less
Lower running costs than 6-cylinder Z4Retractable hardtop, all-weather usable
Timing chain guide weakness on cars built before mid-2015Hardtop hydraulics can fail expensively
Buy if: You want a hardtop roadster with reasonable running costs and can find one built from mid-2015 or one with documented timing chain service.
Avoid if: You are looking at a car built before mid-2015 with no timing chain service history, or you need truly low-maintenance ownership.
Price & maintenance
Used price
€19,000
median asking price, typically 110,000 km
Typical range€18,100 – €21,600
Maintenance cost
€950 – €1,750/year
at 15,000 km/year
Fixed costsservice, tyres, brakes€550 – €900 /yr
Risk bufferunplanned repairs€400 – €850 /yr
Price estimates are based on German asking prices. Prices and costs vary by vehicle condition and location.
Ownership costs
Maintenance assumes 15,000 km a year. Price estimates are based on German asking prices. Prices and costs vary by vehicle condition and location.
Used price
€19,000
Typically €18,100 – €21,600, at around 110,000 km.
Maintenance
€950 – €1,750per year
€550 – €900
service, tyres, brakes
€400 – €850
repair buffer
Price & maintenance
Used price
€24,000
median asking price, typically 85,000 km
Typical range€22,000 – €28,000
Maintenance cost
€950 – €1,750/year
at 15,000 km/year
Fixed costsservice, tyres, brakes€550 – €900 /yr
Risk bufferunplanned repairs€400 – €850 /yr
Price estimates are based on French asking prices. Prices and costs vary by vehicle condition and location.
Ownership costs
Maintenance assumes 15,000 km a year. Price estimates are based on French asking prices. Prices and costs vary by vehicle condition and location.
Timing chain guide failure (engines built before mid-2015)
up to €4,0001 of 8
Plastic chain guides degrade and crack, allowing chain slack that can lead to engine damage · more· less
The N20 engine produced between 2012 and early 2015 uses timing chain guides made from a plastic material prone to becoming brittle with heat cycling. As the guides degrade, the timing chain develops slack, producing a rattling or whining noise, especially noticeable between 1,500 and 2,500 RPM. If ignored, the chain can skip teeth or break entirely, causing catastrophic valve-to-piston contact. BMW acknowledged the issue in the US through a class-action settlement and an extended warranty of 7 years or 70,000 miles (about 112,000 km) for US cars. Replacement involves 10-15 hours of labor: expect approximately €1,500-2,500 at an independent BMW specialist, rising to €3,000-4,000 at a dealer. If the chain has already damaged the engine, costs can escalate dramatically. Engines built from mid-2015 onward received redesigned guides with more durable material and are significantly less affected. When inspecting a car built before mid-2015, listen carefully for any whining, rattling, or ticking from the front of the engine, particularly during cold start.
Gasket hardens and leaks oil; early 2012 cars had plastic housings that could crack and mix oil with coolant · more· less
The oil filter housing gasket is the most common leak point on the N20 engine, typically failing between 60,000 and 100,000 km as the rubber hardens from heat cycling. Oil seeps onto the engine and can drip onto hot exhaust components, producing a burning smell. A straightforward gasket replacement costs approximately €300-500 at an independent shop. However, early 2012 N20 engines used a plastic oil filter housing that could crack between the oil and coolant chambers, allowing the two fluids to mix. BMW released an aluminum replacement housing to address this. If coolant and oil have mixed (check for milky oil or discolored coolant), the housing itself needs replacing, pushing costs to €800-1,200 including diagnosis and labor. The car has no conventional dipstick (the oil level is measured electronically), so during a pre-purchase inspection check the coolant reservoir for oil traces and the oil filler cap for milky residue.
Valve cover gasket leak
up to €7003 of 8
Gasket deteriorates from heat, causing oil to seep onto the exhaust manifold · more· less
The N20 valve cover gasket commonly begins leaking between 80,000 and 120,000 km. Oil seeps from under the cover onto the exhaust manifold side, causing a burning oil smell that is particularly noticeable after highway driving. BMW sells the gasket set separately (part 11127588418), so a leak does not automatically mean a new valve cover. If the cover itself has to be replaced, parts cost approximately €150-250 for an aftermarket cover with integrated gasket, or €300-400 for OEM. Labor runs 2-3 hours. While not immediately dangerous, a persistent valve cover leak will worsen over time and can damage wiring harnesses and other components in the engine bay.
Electric water pump and thermostat failure
up to €1,2004 of 8
Electric water pump fails without warning, causing sudden overheating · more· less
The N20 uses a Pierburg electric water pump that typically fails between 80,000 and 130,000 km. Unlike mechanical pumps, the electric unit fails completely and without advance warning, causing sudden overheating that can damage the engine if not caught immediately. Replacement of pump and thermostat together costs approximately €500-800 at an independent shop, €800-1,200 at a dealer. Many specialists recommend proactive replacement around 100,000 km.
Retractable hardtop hydraulic pump failure
up to €2,5005 of 8
Hydraulic pump or microswitches fail, preventing roof operation or causing it to stall mid-cycle · more· less
The E89's retractable hardtop relies on a hydraulic pump, multiple cylinders, and numerous microswitches. Common failures include water ingress into the pump unit (causing slow operation or complete failure), worn microswitches that lose positional sense (causing the roof to stall mid-cycle), and degraded hydraulic hoses. A full pump replacement at a BMW dealer runs €1,500-2,500 including 8-10 hours of labor. Specialist rebuild services can restore the pump for approximately €700-900 by replacing all internal seals and solenoids. Individual microswitches are inexpensive (€20-30 each) but can be labor-intensive to access. Operating the roof regularly, even during winter, helps prevent seizure. During a test drive, operate the roof at least twice and listen for unusual sounds or hesitation.
Boot water ingress via degraded sealant
up to €5006 of 8
Factory sealant around boot lid and rear lights degrades after approximately 5 years, allowing water in · more· less
This is one of the most widely reported E89-specific issues, affecting all engine variants. The factory sealant strip around the boot lid and rear light cluster seals degrades into a powder-like substance after approximately 5 years, allowing water to enter the boot area and light assemblies. Water can also enter through the air vents on either side of the boot that develop a loose fit over time. Symptoms include misting inside rear lights, corrosion in light assemblies, dampness under the boot carpet, and in severe cases, damage to the roof motor or electronic modules stored in the boot area. BMW updated the rear light seals on 2013+ models. Resealing the affected areas costs approximately €200-300 at a specialist. If light clusters need replacement due to internal corrosion, budget €150-250 per unit. Check the boot carpet carefully during any viewing.
Brake vacuum pump failure (2012-2013 production)
up to €9007 of 8
Camshaft defect starves vacuum pump of oil, leading to reduced brake assist · more· less
BMW recalled Z4 sDrive18i, sDrive20i and sDrive28i models built June 2012 to August 2013 (German campaign announced October 2013) for a defect in the intake camshaft that can reduce oil flow to the engine vacuum pump. If the pump fails, power-assisted braking is lost, though the hydraulic brakes still function with significantly increased pedal effort. BMW dealers installed a locking ring in the camshaft to retain the seal disk as a remedy. This recall should have been performed on all affected cars by now, but verify completion using the VIN. If the recall was not completed and the vacuum pump has failed, replacement costs approximately €400-900 depending on pump condition and associated damage.
Turbo wastegate rattle
up to €2,0008 of 8
Wastegate bushing wears causing metallic rattle at idle; less common than on N54 twin-turbo · more· less
The N20's single twin-scroll turbocharger can develop wastegate rattle as the actuator bushing wears, producing a metallic rattle at idle, deceleration, or engine shutdown. Approximately 7% of N20 owners report turbo-related problems. This is far less common than on the N54 twin-turbo (used in the sDrive35i) but does occur, particularly on engines with infrequent oil changes or those that have been tuned. Wastegate-only repair costs approximately €500-800, while full turbo replacement runs €1,200-2,000 including labor. Premium synthetic oil meeting BMW LL-01 specification and regular oil changes every 10,000-12,000 km, a shorter preventive interval than BMW's Condition Based Service sets by usage, help prevent this issue.
Simpler than the inline-6 variants, but timing chain and leaks need monitoring
The N20-powered Z4 sDrive28i is significantly less complex (and less expensive to maintain) than the N54-powered sDrive35i. The main concern is the timing chain guide issue on engines built before mid-2015, which can cause catastrophic engine damage if missed. Oil leaks from the filter housing and valve cover are very common on higher-mileage examples but are manageable repairs. The E89-specific retractable hardtop and boot water ingress affect all variants regardless of engine. Prioritize cars with documented timing chain service (for cars built before mid-2015) or cars built from mid-2015 with redesigned guides, and verify all recalls have been completed.
Service history
Complete BMW dealer or specialist records essential. Verify oil change intervals (10,000-15,000 km or 12 months). The N20 is sensitive to oil quality and change frequency.
Cold start
Must start engine completely cold. Listen for rattling, whining, or ticking from the front of the engine in the first 30 seconds. N20 does sound slightly diesel-like at idle due to direct injection, which is normal.
Test drive
Minimum 30 minutes including varied speeds. Watch for warning lights, boost loss, and rough shifting. Get the engine fully up to temperature.
Underside inspection
Check for oil leaks around the oil filter housing, valve cover, and oil pan. Some oil residue is common on higher-mileage N20 engines but active dripping indicates overdue repairs.
Specific for this vehicle
Listen for timing chain noise at 1,500-2,500 RPM
A high-pitched whining or rattling sound from the front of the engine at these revs is the most important warning sign. Particularly critical on cars built before mid-2015. Ask if timing chain has been replaced.
Check oil and coolant for cross-contamination
Milky residue under the oil filler cap or discolored coolant can indicate a cracked oil filter housing (especially on early 2012 cars with the plastic housing). This is a serious concern.
Operate the retractable hardtop fully (twice)
Open and close the roof at least twice. Listen for unusual hydraulic sounds, watch for hesitation or stopping mid-cycle. Note operation speed, as slow operation suggests pump wear.
+ 3 more checksShow less
Inspect boot area for water damage
Lift boot carpet and check for dampness, water staining, or corrosion. Check rear light clusters for misting or condensation inside. Water damage to boot-area electronics can be expensive.
Verify recall completion
Contact BMW with the VIN to confirm the brake vacuum pump recall (built June 2012 - August 2013) has been completed, and on UK cars built 1 November - 31 December 2011 the steering box recall.
Check coolant level and system pressure
Low coolant can indicate water pump deterioration, thermostat housing cracks, or plastic coolant hose failures. The N20 cooling system uses several plastic components that degrade with age.
Recalls and Technical Service Bulletins
Brake vacuum pump oil starvation (sDrive18i/20i/28i built June 2012 - August 2013; German campaign announced October 2013)Verify completed
Electric power steering assistance could fail; steering box replaced (UK R/2012/081, July 2012: Z4s built 1 November - 31 December 2011)Verify with VIN
Contact BMW with the VIN to verify all recalls have been completed. The brake vacuum pump recall covers cars built June 2012 to August 2013, and in the UK, Z4s built 1 November to 31 December 2011 were recalled to replace the steering box because electric power steering assistance could fail.
Warranty Status
Factory warranty (2 years)Expired on all E89 Z4 models
Rust perforation warranty (12 years)May still apply for 2014-2016 models
All E89 Z4 sDrive28i models are outside their original 2-year factory warranty. BMW's timing chain and thermostat warranty extensions were US programmes. Budget for all maintenance and repairs without warranty coverage.
